Organ Projects

Scott Smith Pipe Organs, Lansing, Michigan

Grace Lutheran Church, Auburn, Michigan

Auburn is a modest-sized city of just over 2,000 in the Great Lakes Bay Region of Michigan, nearly equidistant from Midland to the west, Bay City to the east, and slightly farther from Saginaw to the south. As a result, the churches in this region draw members from a rather diverse culture, comprising everything from chemical engineering to manufacturing to agriculture.

Around 1980, a local builder moved a small, two-manual Wicks organ into Grace Lutheran from a church in Maple Heights, Ohio, replacing an electronic substitute. In 1986, the church expanded in size, and the organ was moved to the rear of the sanctuary and enlarged to fifteen ranks.

The instrument came to us as a new service account a few years ago. Almost immediately, Nathan Beethe, the church’s music director, initiated what was to become an ongoing discussion about the condition of the organ, its built-in constraints, and some changes he would like to see. Chronic dead notes and ciphers were only the beginning. The organ’s overall character was harsh and loud, posing constant challenges in registration choices, particularly for offertories and choir accompaniment. Perhaps the most annoying issue for organists was the failing console and the limitations posed by its 56-note manual compass controlling 61-note chests.

Soon, the church underwent a facility-wide upgrade, and the organ became an integral part of that overall improvement. The first thing we asked the church to do was to beef up the back wall of the chamber, as the 16′ Subbass was sorely lacking in projected power into the sanctuary. Its bass sound waves were being transmitted through a single layer of gypsum board to the chapel behind. The vibration of the 16′ Subbass vigorously shook the chapel’s shared back wall on the other side of the studs. An additional layer of gypsum board had a dramatic effect of focusing the bass tones, and the Subbass could be heard and felt for the first time in the surprisingly good acoustic of the sanctuary.

Joe Granger of our team worked with Organ Supply Industries on the design of a new console, which offers two 61-note manuals and an exterior cabinet of red oak in a diagonal shiplap design that matches the cabinetry of the organ casework. The elegant new console features drawknobs instead of the tongue tabs on the old unit. Joe collaborated with Kantor Beethe to develop the new specification.

In our opinion, a fifteen-rank organ did not require three 2′ stops, so the Swell 2′ Principal was replaced by a 100-year-old Austin 4′ Harmonic Flute. Its positioning near the Swell opening helps to enhance the delicate spray of harmonics from this beautiful stop that sounds surprisingly at home in the instrument.

The Swell 16′ Trumpet was judged to be too harsh and too thin to adequately cap the rest of the organ in big ensembles and did not work well as a solo stop. Limited by space and therefore unable to install a larger-scaled reed, we handed the work of transforming the stop over to Oyster Pipeworks of Louisville, Ohio. They successfully merged portions of the existing rank with another to create one whose overall character now possesses tones that are darker, warmer, and more pleasing in both ensemble and solo work.

As it stood, we felt that the Great III Mixture (11⁄3′) spoke an octave too high. Through the magic of computer programming, the rank was repitched an octave lower, but still remains available at the original pitch for those occasions when the extra “spice” is desired without the aid of an octave coupler.

The Great 8′ Rohr Schalmei was of limited usage and was replaced with a vintage 8′ Clarinet, believed to have been made by Hook & Hastings.

To make this modest-sized organ as versatile as possible, we made extensive use of the Swell 8′ Viole, which is now also available as a three-rank derived Swell III Mixture (2′, breaking), Swell 11⁄3′ Larigot, and Great Grave Mixture II (2′ and 22⁄3′, non-breaking). This medium-scale, rather generic string was nearly perfect as it stood to provide the basis for these faux stops, in addition to its normal duty as the Swell Viole.

In the 1986 expansion, the low twelve Pedal 16′ Subbass pipes were extended upward for the next twenty notes with chunky zinc/spotted metal pipes, which were never very effective, nor did they match well. These were replaced with wood pipes, merging two vintage Estey sets, and rescaled to match the Wicks Subbass. The end result now brings warmth and power to the entire compass of the organ’s bass. Combining these two nearly identical sets also allowed us to slow down the halving ratio in the treble portion of its compass.

Today, the instrument’s ensemble is warmer, darker and fuller than before, without sacrificing a great deal of its brilliance. The reworked swell mechanism now provides greater and more subtle dynamic control, and the revised stoplist offers a more diverse palette of options for the organist. A Peterson ICS-4000 organ control system was chosen for the relay and multi-level combination action.

We acknowledge Richard Swanson of R. T. Swanson, Inc., who initially consulted on and assisted with installation of the first two incarnations of this instrument, and freely shared his file and drawings with us.

—Joe Granger, Scott Smith; Scott Smith Pipe Organs, Lansing, Michigan

Photos by Joe Granger

GREAT (Manual I)

16′ Bourdon Doux (Sw 16′ Bourdon)

8′ Diapason 61 pipes

8′ Bourdon 73 pipes

8′ Viole (Sw 8′ Viole)

8′ Viole Celeste (TC) (Sw 8′ Viole Cel)

4′ Octave 61 pipes

4′ Flute (ext 8′ Bourdon)

2′ Principal Conique 61 pipes

III Mixture (22⁄3′) 183 pipes

III Cymbale (11⁄3′) (fr III Mixture)

II Grave Mixture (fr Sw 8′ Viole)

16′ Contre Trompette (Sw 16′ C Trom)

8′ Trompette (Sw 16′ Contre Tromp)

8′ Clarinet 61 pipes

Chimes 21 tubes

Great 16

Great Unison Off

Great 4

Zimbelstern

SWELL (Manual II, enclosed)

16′ Bourdon 97 pipes

8′ Bourdon (ext 16′ Bourdon)

8′ Flute Conique (1–12 fr 16′ Bour,, 13–61 fr 4′ Flute Conique)

8′ Viole 85 pipes

8′ Viole Celeste (TC) 49 pipes

4′ Flute Harmonique 61 pipes

4′ Flute Conique 61 pipes

4′ Viole (ext 8′ Viole)

2-2⁄3′ Nasard (ext 16′ Bourdon)

2′ Flute (ext 16′ Bourdon)

1-3⁄5′ Tierce (fr 16′ Bourdon)

1-1⁄3′ Larigot (fr 8′ Viole)

III Plein Jeu (2′)(fr 8′ Viole)

16′ Contre Trompette 85 pipes

8′ Trompette (ext 16′ Contre Tromp)

4′ Clarion (ext 16′ Contre Tromp)

Swell 16

Swell Unison Off

Swell 4

Tremolo

PEDAL

32′ Resultant (16′ Soubasse, 10-2⁄3′ Bdn)

16′ Soubasse 44 pipes

16′ Bourdon (Sw 16′ Bourdon)

8′ Flute (ext 16′ Soubasse)

8′ Bourdon (Sw 16′ Bourdon)

8′ Diapason (Gt 8′ Diapason)

4′ Flute (Sw 16′ Bourdon)

4′ Octave (Gt 4′ Octave)

16′ Contre Trompette (Sw 16′ C Trom)

8′ Trompette (Sw 16′ Contre Tromp)

COUPLERS

Great to Pedal 8

Great to Pedal 4

Swell to Pedal 8

Swell to Pedal 4

Swell to Great 16

Swell to Great 8

Swell to Great 4

ACCESSORIES

10 General pistons (thumb and toe)

5 Great pistons (thumb)

5 Swell pistons (thumb)

3 Pedal pistons (toe)

General Cancel (thumb)

Setter (thumb)

Great to Pedal reversible (thumb and toe)

Swell to Pedal reversible (thumb and toe)

Swell to Great reversible (thumb and toe)

Sforzando (thumb and toe)

Combination level, up or down (thumb)

Transposer (up/down, thumb)

R. M. Ballantyne Pipe Organs,

Jurupa Valley, California

Pasadena Stake Center,

The Church of Jesus Christ of Latter-day Saints,

Pasadena, California

R. M. Ballantyne Pipe Organs has completed an extensive rebuild and enhancement of M. P. Möller Opus 10181 from 1966 in the Pasadena, California, Stake Center of The Church of Jesus Christ of Latter-day Saints. Ballantyne has serviced the instrument for years and was hired to rebuild the instrument. Our intent in working with local membership was to take advantage of some of the tonal changes made previously to this organ by other firms and complete their work. The goal was to make this organ as flexible as possible for the worship services of the Stake. Our scope included the following improvements and restorative work:

1. cleaning of the organ and its pipes

2. rebuilding of windchests and actions

3. rebuilding of six wind regulators

4. repairing or replacing damaged Möller windlines

5. rebuilding the console and providing a solid state control system

6. rebuilding the blower and installing a variable frequency drive

7. adding much needed service lighting both above and below the organ’s windchests

8. unification of the playing action of the Swell #1 main chest to allow for additional Trumpet, string, and principal stops

9. restoration to the Great of the original Möller 22⁄3′ and 2′ Grave Mixture as independent stops

10. addition or extension of the following ranks:

a) 8′ Melodia (61 pipes) added to the Great (from Murray Harris Opus 73)

b) extension of Great Spitzflöte by 12 notes and relocation to Bassoon unit actions

c) relocation of exposed Pedal 16′-8′ unit Bassoon to the Swell and the addition of 17 pipes to complete the compass of the stop, as well as new chests in the Swell

d) extension of Swell Trumpet by 12 notes using Peterson generators

e) addition of 12 bass pipes to complete compass of Swell 8′ Geigen Diapason

f) addition of 22⁄3′ Nazard and chest of 61 notes to the Swell

g) addition of 2′ Blockflöte of 61 notes to the Swell

h) addition of 13⁄5′ Tierce of 61 notes to the Swell

i) addition of Zimbelstern by Klann

j) addition of chimes and chime action to the Great.

The Ballantyne firm offers special thanks to Bruno Lagarce for console amd restoration work, and to A. R. Schopp’s Sons, Inc., for providing the new pipework. The instrument was rededicated by local leadership and a recital was given by David Chamberlin in summer of 2016.

—Ryan Ballantyne

Photo credit: Ryan Ballantyne

Builder’s website: www.rmballantyne.com

GREAT

16′ Bourdon (Sw)

8′ Open Diapason (61 pipes)

8′ Melodia (61 pipes)

8′ Bourdon (Sw)

8′ Spitzflöte (73 pipes)

8′ Viola (Sw)

8′ Voix Celeste (Sw)

4′ Octave (61 pipes)

4′ Spitzflöte (ext 8′)

22⁄3′ Twelfth (61 pipes)

2′ Fifteenth (61 pipes)

III Mixture (draws 2′, 122 pipes)

8′ Trumpet (Sw)

8′ Oboe (Sw)

Chimes

Great to Great 16

Great Unison Off

Great to Great 4

Swell to Great 16

Swell to Great 8

Swell to Great 4

Automatic Pedal

SWELL (enclosed)

16′ Contra Viola (ext)

8′ Geigen Diapason (73 pipes)

8′ Bourdon (73 pipes)

8′ Viola (61 pipes)

8′ Voix Celeste (TC, 49 pipes)

4′ Geigen Octave (ext 8′)

4′ Koppel Flute (61 pipes)

22⁄3′ Nazard (61 pipes)

2′ Blockflöte (61 pipes)

13⁄5′ Tierce (61 pipes)

11⁄3′ Larigot (from 22⁄3′)

16′ Bassoon (73 pipes)

8′ Trumpet (61 pipes)

8′ Oboe (ext 16′)

4′ Clarion (fr 8′)

Tremulant

Swell To Swell 16

Swell Unison Off

Swell to Swell 4

PEDAL

32′ Resultant (fr Bourdon)

16′ Principal (ext Gt 8′, 12 pipes)

16′ Bourdon (Sw)

8′ Octave (Gt)

8′ Bourdon (Sw)

8′ Spitzflöte (Gt)

4′ Choral Bass (Gt)

4′ Gedeckt (Sw)

16′ Trombone (12 generators)

8′ Trumpet (Sw)

8′ Bassoon (Sw)

4′ Bassoon (Sw)

Great to Pedal 8

Swell to Pedal 8

Swell to Pedal 4

Zimbelstern

The Saint Cecilia Organ, Church of the Transfiguration; Community of Jesus, Orleans, Massachusetts

If we all embrace a new vision, special guidance and support will surely come.

—Nelson Barden

On Monday, May 15, 1995, at 10:56 p.m., a fax from Nelson Barden (president, Nelson Barden & Associates, restorer-in-residence, Boston University) arrived in the music office. This was not just another fax. This document was in response to Nelson’s first visit to the Community of Jesus to meet with the superior, Mother Betty Pugsley, during which they discussed the vision, need, scope, and reason for an organ of incredible depth, proportion, beauty, and scale that would support the worship at the Community of Jesus and its world-renowned music outreach. Nelson realized instantly and exactly what she was saying, and both agreed that, “Above all other considerations, this organ must uncompromisingly spring from its spiritual and artistic vision until that vision becomes reality.”

To that end, the organ’s specification, geographic layout, and overall design were inspired and motivated by the ministry and mission of Gloriæ Dei Cantores (the resident professional choir at the Community of Jesus) as well as the community’s enthusiastic hymn singing. Gloriæ Dei Cantores performs repertoire of more than thirty nationalities, from Gregorian chant to music of the present day—a challenge for any organ to support, given the number of genres this includes!

Before meeting Nelson, we had committed to the restoration of an E. M. Skinner organ for the Church of the Transfiguration, knowing the innate beauty and flexibility of these instruments. In fact, we had already purchased, and had in storage, Skinner Organ Company Opus 762 from the Munn Avenue Presbyterian Church in East Orange, New Jersey. We soon realized, however, that this instrument would not be enough on its own and instead would need to become the basis for something far larger and with greater impact. In order to fulfill his vision and charge to unite the organ with the basilica form of the church, Nelson said, “Surround Sound:”

For this installation, I suggest rotating the traditional east-west organ placement 90 degrees to north-south and stretching the instrument completely down the nave in balconies over both side aisles. The divisions would start near the chancel (above the choir seating) with the Swell and Choir on opposite sides. These would be followed by an exposed Great and an Enclosed Great (including some Pedal) to broaden the tone and bring it down the nave . . . . Next would be matching north and south Solo divisions, followed by North and South Orchestral. These paired divisions would contain similar but distinct voices. These four matched divisions would form the “moving melody” section. . . . Near the west end would be the Bombarde/Antiphonal opposite the Echo. The shades of these divisions would not open directly toward the congregation but project the sound toward the back wall. This would modulate the heavy hitters in the Bombarde and allow the Echo to do a tonal “disappearing act.” The directional and surround effects achieved by computer control of stops and shades would lift the instrument beyond state-of-the-art into a unique realm. Moving melody could range freely over the building from left to right and front to back . . . . A single pianissimo chord from the chancel could grow into a mighty wave of sound, roll down the entire length of the nave, cascade into the Echo, and disappear.

Over the course of many years, there ensued hundreds of discussions about the numerous specifics needed to arrive at such a conclusion. (The specification alone has been through more than 150 revisions!) Only two weeks after the first fax came the next “prophetic” fax that would soon reveal the platform upon which we would collaborate for more than two and a half decades.

In addition to the primary precept of always maintaining the spiritual and artistic vision, two other significant points were developed from this second exchange:

1. Encourage apprentice-interested Community of Jesus members into the organ building field to act as good stewards in both the construction and future care of this instrument; and

2. Let the project take the time required for the organ to “teach and tell us” how it should grow and be transformed through varied experiences.

Upon mutually enthusiastic agreement, we reviewed the concepts set forth in the May 15 document in which Nelson said the organ should be:

1. World-class and unique

2. Ideally suited to your purposes

3. A tangible expression of Community of Jesus spiritual principles

4. Beautiful and musical, with instantly recognizable tone

5. Designed for posterity; built to last forever

6. Able to perform both nineteenth-century music authentically and eighteenth-century Bach convincingly

7. Capable of eliciting profound emotions

8. Designed for HDCD recordings

9. Focused on future developments, not current technology

10. A “trend setter.”

These discussion points quickly converted into:

1. Adopting the vision

2. Making the commitment to move forward

3. Incorporating the organ space into the church design

4. Refining the vision, shaping it to our precise needs

5. Defining the mechanical system of the organ

6. Developing a plan of action and a realistic budget

7. Locating a shop and storage space

8. Beginning to implement the plan of action

9. Training part-time workers and develop their expertise

10. Acquiring more component parts to restore

11. Organizing and commencing restoration work

12. Setting up a division and playing it for inspiration!

Thus, the organ restoration project began in earnest.

Fast forward to the summer of 2021, and we look back to see that Nelson’s original division layout, with some changes in nomenclature, has come true. The disposition of the divisions is as follows:

APSE

Choir Swell

North Gt (& Ped) South Gt (& Ped)

Solo (& Pedal) String (& Pedal)

Antiphonal/Processional Echo

WEST END

We were extremely fortunate to find instruments available for purchase that, together, created a “joyful musical genesis.” Below is a partial list of the Skinner organs whose components constitute this “new” instrument:

Opus 140, Trinity Episcopal Cathedral, Cleveland, Ohio

Opus 195, Williams College, Williamstown, Massachusetts

Opus 310, Plymouth Church, Shaker Heights, Ohio

Opus 473, Florida State University, Tallahassee, Florida

Opus 540, Saint Paul’s Lutheran Church, Williamsport, Pennsylvania

Opus 541, First Congregational Church, St. Petersburg, Florida

Opus 655, Saint Paul’s Episcopal Church, Rochester, New York

Opus 656, Princeton University, Princeton, New Jersey

Opus 762, Munn Avenue Presbyterian Church, East Orange, New Jersey

Opus 855, Sacred Heart Catholic Church, Pittsburgh, Pennsylvania

Opus 858, Rollins College, Winter Park, Florida

Opus 934, Saint Joseph’s College, Adrian, Michigan

Opus 991, Broadway Tabernacle, New York, New York

Opus 1242, First Baptist Church, Abilene, Texas

Nelson and the Community of Jesus have maintained an organ building apprenticeship program over these many years, having trained one of our members to journeyman status (over the course of twenty years), and four others in multi-year, work-training situations. During this time, the construction and installation truly did follow Nelson’s initial concept—division by division. This is what allowed the organ to “teach” us. Below are some other significant dates in the history of this organ:

June 2000: Dedication of the Church of the Transfiguration: North Great, Swell, and Tuba Mirabilis

June 2003: Great Artist series begins with American Guild of Organists Regions I and II convention, featuring Thomas Murray: Choir division

June 2005: Fifth anniversary of the Church of the Transfiguration: Antiphonal/Processional divisions

June 2010: Tenth anniversary of the Church of the Transfiguration: Echo division and arrival of the West End console for the concerts by Gerre and Judith Hancock and Thomas Murray

Summer 2018: 32′ Bombarde installed on South side

Summer 2019: removal of 1929 console and return of the rewired west end console serving as temporary main console

February 2020: Arrival of the final console

Our new console was designed, constructed, and installed by Richard Houghten and Joseph Zamberlan. From 2000 until 2020, we had used the original Skinner Organ Company console from Opus 762, which by 2020 the organ had long outgrown. The new console was designed to be as comfortable as a Skinner one, with everything clearly identified and within reach. Special features include shade expression thumb slides underneath the bottom three keyboards, an expression matrix so that any of the divisions can be assigned to a specific swell shoe (the entire organ is under expression), ivory keyboards that came from the Opus 762 console and are E. M. Skinner’s “tracker touch.” Some unusual couplers such as pedal to manual are included.

Perhaps the most moving realizations are the visionary outlooks of how this organ would affect people as they listened and experienced it in the setting of the Church of the Transfiguration. In concluding his initial thoughts to us in May 1995, Nelson wrote this to encourage us to take this on:

The Ultimate Goal

Every church is an expression of the builders, and so is every organ. When this instrument is finished, Community members will feel they are a part of the organ, and the organ is part of them. It will give voice to their aspirations and resonate with deep-seated meaning.

Building a magnificent instrument is hard work, sometimes tedious and always prolonged. Non-professionals may become discouraged, just as organ builders are when the job drags on. The difference is that organ builders hold a vision that gives them boundless energy and faith. They know the end result and imagine how it sounds.

Community members will understand everything when their labor comes to life and the organ starts to play. Lumber and leather, wire, and wind—if a pipe organ can sing with the angels, isn’t there hope for us all?

The list of people to thank is simply endless at this point, but here are names of those without whom this organ would not exist:

Mother Betty Pugsley

Nelson Barden

Sean O’Donnell

Joseph Sloan

Joseph Rotella

John Ananda

Jonathon Ambrosino

Duane Prill

William Czelusniak

Richard Houghten

Joseph Zamberlan

Christopher Broome

David Broome*

James Hudson Crissman

Peter Rudewicz

Thomas Murray

David Craighead*

Gerre Hancock*

*deceased

To learn more, please visit our website, www.communityofjesus.org.

—Nelson Barden and Jim Jordan

Since 1956, Nelson Barden has been recognized as one of America’s leading experts in the museum quality restoration of orchestral pipe organs—particularly the work of E. M. Skinner—and is President of Nelson Barden & Associates.

Jim Jordan is one of the organists in residence at the Church of the Transfiguration at the Community of Jesus since 1988, during which has performed as an organ accompanist for Gloriæ Dei Cantores, and a soloist throughout the United States and Eastern and Western Europe.

RELATED: View a video about the project here

Nelson Barden & Associates

Church of the Transfiguration, Orleans, Massachusetts

NORTH GREAT

1. 16′ Violone 73

2. 8′ First Diapason 61

3. 8′ Second Diapason 61

    8′ Violone --

4. 8′ Harmonic Flute 61

5. 8′ Gemshorn 61

6. 8′ Gemshorn Celeste (TC) 49

7. 4′ Octave 61

8. 4′ Harmonic Flute 61

9. 2′ Fifteenth 61

10. Willis Mixture IV 244

15 19 22 26 12

12 15 19 22 24

8 12 15 19 12

1 8 12 15 13

11. 16′ Posaune 61

12. 8′ Cornopean 61

13. 4′ Clarion 61

Tremolo

North Great Sub

North Great Unison Off

North Great Super

8′ Tuba Mirabilis Choir

8′ Tuba Major Processional

8′ Trompette Militaire Processional

SOUTH GREAT

14. 16′ Gedecktpommer 68

15. 8′ Stentorphone 73

16. 8′ Principal 61

17. 8′ Bourdon 61

18. 4′ Octave 61

19. 4′ Nachthorn 61

20. 2-2⁄3′ Twelfth 61

21. 2′ Fifteenth 61

22. Fourniture III–V 245

15 19 22 12

12 15 19 22 12

8 12 15 19 12

1 8 12 15 12

1 5 8 12 15 13

23. Scharff III–IV 220

15 19 22 18

12 15 19 6

12 15 17 19 18

8 12 15 17 6

8 10 12 15 13

24. 16′ Willis Trombone 56

25. 8′ Willis Trumpet 61

26. 8′ Hautbois 68

27. 4′ Clairon 68

Tremolo

South Great Unison Off

East Chimes

SWELL

28. 16′ Bourdon 73

29. 8′ Diapason 73

30. 8′ Salicional 73

31. 8′ Voix Celeste 73

      8′ Bourdon (ext 16′ Bourdon) --

32. 8′ Rohrflöte 61

33. 8′ Flauto Dolce 73

34. 8′ Flute Celeste (TC) 61

35. 4′ Octave 73

36. 4′ Triangle Flute 73

37. 2′ Flautino 61

38. Willis Mixture IV 244

15 19 22 26 12

8 12 15 19 36

1 8 12 15 13

39. 16′ Waldhorn 73

40. 8′ Trumpet 73

41. 8′ Oboe d’Amour 73

42. 8′ Vox Humana 73

43. 4′ Clarion 61

Tremolo

Swell Sub

Swell Unison Off

Swell Super

8′ Tuba Mirabilis Choir

8′ Tuba Major Processional

8′ Trompette Militaire Processional

Orchestral Bells

Orchestral Harp

ANTIPHONAL

44. 16′ Lieblich Bourdon 61

45. 8′ Diapason 73

46. 8′ Gross Flute 73

47. 8′ Clarabella 73

48. 8′ Erzähler Celeste II (celeste TC) 134

49. 4′ Principal 61

50. 4′ Harmonic Flute 61

51. Mixture IV 244

12 15 19 22 18

8 12 15 19 12

1 8 12 15 31

Tremolo

Antiphonal Sub

Antiphonal Unison Off

Antiphonal Super

CHOIR

52. 16′ Erzähler 85

53. 8′ Diapason 73

54. 8′ Cello 73

55. 8′ Cello Celeste 73

56. 8′ Viola 73

57. 8′ Viola Celeste 73

58. 8′ Concert Flute 73

59. 8′ Lieblich Gedeckt 73

      8′ Erzähler --

60. 8′ Erzähler Celeste 73

61. 8′ Aeoline Celeste II (celeste TC) 110

62. 4′ Principal 73

63. 4′ Flute 61

64. 2-2⁄3′ Nazard 61

65. 2′ Piccolo 61

66. 1-3⁄5′ Tierce 61

67. 1′ Sifflöte (to f54) 54

68. Low Mixture III–IV 207

15 19 22 12

12 15 19 12

8 12 15 13

1 8 12 15 24

69. High Mixture III 183

22 26 29 18

19 22 26 12

15 19 22 12

12 15 19 6

8 12 15 13

70. 16′ Heckelphone 73

      8′ Heckelphone --

71. 8′ Flügel Horn 73

72. 8′ English Horn 73

73. 8′ Clarinet 73

Tremolo

74. 8′ Tuba Mirabilis 67

Choir Sub

Choir Unison Off

Choir Super

PROCESSIONAL

75. 8′ Principal Diapason 73

76. 8′ Gamba Celeste II 146

77. 8′ Orchestral Flute 73

78. 8′ Chorus Trumpet 73

Tremolo

79. 8′ Tuba Major 73

80. 8′ Trompette Militaire 73

Processional Sub

Processional Unison Off

Processional Super

STRING

      16′ Double Violin (Kimball, ext) --

      16′ Contra Viol (Haskell, ext. Ætheria)

81. 16′ Bourdon 73

82. 8′ Diapason 61

83. 8′ Violin 85

84. 8′ Violin Celeste 73

85. 8′ Cello 73

86. 8′ Cello Celeste 73

87. 8′ Flared Gamba 73

88. 8′ Flared Gamba Celeste 73

89. 8′ Gross Gamba 73

90. 8′ Gross Gamba Celeste 73

91. 8′ Cellos II (flat-front) 134

92. 8′ Salicional 73

93. 8′ Voix Celeste 73

94. 8′ Viole Ætheria 97

95. 8′ Viole Ætheria Celeste (TC) 61

96. 8′ Voix Celeste II (celeste TC) 110

97. 8′ Chimney Flute 73

98. 8′ Dulciana 73

99. 8′ Unda Maris (TC) 61

100. 8′ Quintadena 73

101. 8′ Quintadena Celeste (TC) 61

102. 8′ Flute Celeste II (celeste TC) 110

      4′ Violin Celeste II --

      4′ Violina Ætheria --

      4′ Voix Celeste II --

103. 4′ Triangle Flute 61

104. 2-2⁄3′ String Nazard 61

      2′ Violette

105. 1-3⁄5′ String Tierce (to c49) 49

106. 8′ Cornopean 61

107. 8′ French Horn 61

108. 8′ English Horn (free reed) 61

109. 8′ Oboe (labial) 61

110. 8′ Vox Humana (TC) 49

Tremolo

String Sub

String Super

String Unison Off

SOLO

111. 8′ Horn Diapason 73

112. 8′ Flauto Mirabilis 73

113. 8′ Saxophone (wood) 73

114. 8′ Viola 73

115. 8′ Viola Celeste 73

116. 8′ Dulcet II 146

117. 8′ Silver Flute 73

118. 4′ Concert Flute 61

119. 4′ Viole Celeste II 122

      4′ Silver Flute --

120. 8′ English Horn 73

121. 8′ Labial Clarinet 61

122. 8′ Orchestral Oboe 73

Tremolo

8′ Tuba Mirabilis Choir

8′ Tuba Major Processional

8′ Trompette Militaire Processional

Tremolo

Solo Sub

Solo Unison Off

Solo Super

Orchestral Harp

Harp

Orchestral Bells

East Chimes—West Chimes

ECHO

123. 8′ Echo Principal 61

124. 8′ Gamba 66

125. 8′ Dulcet Celeste II 146

126. 8′ Philomela 73

127. 8′ Fern Flute 73

128. 8′ Wood Celeste (TC) 49

129. 8′ Muted Viole 73

130. 8′ Muted Viole Celeste 73

131. 8′ Spitzflute Celeste II (celeste TC) 134

132. 8′ Double-Enclosed Aeoline 61

133. 4′ Fugara 61

134. 4′ Harmonic Flute 61

135. 2′ Piccolo 61

16′ Clarinet (Bassoon bass) 12

136. 8′ Clarinet (free-reed) 73

Tremolo

137. 16′ Bass Vox 73

138. 8′ Baritone Vox 73

139. 8′ Tenor Vox 73

140. 8′ Alto Vox 73

141. 8-4′ Soprano Vox I-II 112

142. 8′ Vox Humana (doubly-enclosed) 61

143. Aeolian Mixture IV–V 275

8 12 15 17 18

1 8 12 15 17 31

1 8 12 15 12

Vox Chorus Tremolo

PEDAL

      64′ Gravissima --

      32′ Open Wood (ext Major Bass) 12

      32′ Erzähler (ext Choir) 12

144. 16′ Open Wood 56

145. 16′ Major Bass (wood, Haskell bass) 44

146. 16′ Open Diapason (metal) 32

      16′ Double Violin String

      16′ Violone North Great

      16′ Contra Viol String

     16′ Erzähler Choir

      16′ Bourdon Swell

      16′ Echo Bourdon String

      16′ Lieblich Bourdon Processional

 .    16′ Gedecktpommer South Great

147. 16′ Quintadena (in Echo) 32

      8′ Open Wood --

148. 8′ Principal 44

      8′ Major Bass --

      8′ Violone North Great

      8′ Viol Ætheria String

      8′ Concert Flute Choir

      8′ Erzähler Choir

      8′ Gedeckt Swell

      8′ Still Gedeckt String

      8′ Lieblich Gedeckt Processional

      4′ Octave --

      4′ Concert Flute Choir

      4′ Erzähler Choir

      4′ Gedeckt Swell

      32′ Bombarde --

      32′ Waldhorn (TC) Swell

149. 16′ Bombarde 56

      16′ Posaune North Great

      16′ Willis Trombone South Great

      16′ Waldhorn Swell

      16′ Heckelphone Choir

      16′ Clarinet Echo

      8′ Bombarde --

      8′ Heckelphone Choir

      8′ English Horn Choir

      4′ Heckelphone Choir

      8′ Tuba Mirabilis Choir

      8′ Tuba Major Processional

      8′ Trompette Militaire Processional

COUPLERS

N. Great to Pedal

N. Great to Pedal 4

S. Great to Pedal

S. Great to Pedal 4

Swell to Pedal

Swell to Pedal 4

Choir to Pedal

Choir to Pedal 4

Solo to Pedal

Solo to Pedal 4

Swell to Great 16

Swell to Great

Swell to Great 4

Choir to Great 16

Choir to Great

Choir to Great 4

Solo to Great 16

Solo to Great

Solo to Great 4

Solo to Swell

Choir to Swell

Great to Solo

Swell to Solo

Swell to Choir 16

Swell to Choir

Swell to Choir 4

Solo to Choir 16

Solo to Choir

Solo to Choir 4

String on Great

Echo on Great

Antiph. on Great

Proc. on Great

String on Swell

Echo on Swell

Antiph. on Swell

Proc. on Swell

String on Choir

Echo on Choir

Antiph. on Choir

Proc. on Choir

String on Solo

Echo on Solo

Antiph. on Solo

Proc. on Solo

BALANCED PEDALS

I—II—III—IV—V/Crescendo

EXPRESSION THUMB SLIDES

Swell—Great—Choir

EXPRESSION MATRIX

Assigns any of the following onto any or all of the balanced pedals and thumb slides. When an enclosure or control is assigned to more than one pedal or slide, the pedal or slide open furthest takes precedent.

North Great

South Great

Swell

Choir

Solo

Echo (west end only)

Interior Echo (speaking into String enclosure)

String

Pedal

Antiphonal

Processional

Tremolo Speed

Tremolo Depth

All Swells

The Matrix has its own divisionals

Standard–1–2–3–4–5–6–7

COMBINATIONS

Generals 1–25 / 1–10 Thumb/Toe

Great 1–10 Thumb

Swell 1–10 Thumb

Choir 1–10 Thumb

Solo 1–8 Thumb

Pedal 1–10 Toe

Great to Pedal Thumb/Toe

Swell to Pedal Thumb/Toe

Choir to Pedal Thumb

Solo to Pedal Thumb

All Divisionals Next – All Generals Next

Next and Previous (multiple)

Library – Scope – Set – Cancel

Solid State Organ Systems Organist Palette

149 independent stops

185 ranks

11,964 pipes

Roger Banks,

Oklahoma City, Oklahoma

Reuter Organ Company,

Lawrence, Kansas

First Presbyterian Church,

Oklahoma City, Oklahoma

From Roger Banks

I first heard the M. P. Möller organ at First Presbyterian Church shortly after its installation in 1964. At that time, I was a senior at Oklahoma City University nearby. As one of the newest and largest organs in the Oklahoma City area, it should have been wonderful. After all, the specification indicated that it followed the latest trends in organbuilding and design at the time, yet I remember that, in that cavernous building, the result was much less
than satisfying.

In the intervening time between then and now, I have fully transitioned from the spare but well-intentioned organ sounds of the 1960s and 1970s, through the 1980s and 1990s, to arrive at my current tonal philosophy, which favors broader scales and divisions featuring rich fundamental tone. Thus I was delighted when John Edwards entrusted me with the care of the instrument at First Presbyterian.

The first project we undertook was to replace the failing Swell division expression pneumatics. That opened up the shade front to fully allow the sound to enter the chancel area rather than bounce off the ceiling. The improvement was immediate and quite noticeable. In 1994, the previous technician installed a new console. However, this large console appeared to have more prepared drawknobs than actual stops. I suggested that John Edwards consider not only completing the console preparations, but also replacing and/or rescaling most of the Great principal chorus as well as adding foundation stops to the other divisions. We decided to make it a two-year project to better utilize the available funding source.

It did not take long for us to realize that rescaling the existing Great 8′ Principal was hopeless. The lowest fourteen pipes were in the façade, scale 46, and nearly forced double length by the façade design. The 4′ Octave rescaled nicely, but the 2′ Weit Prinzipal as well as the IV- and III-rank mixtures were not be able to be reused. The new principal chorus that was added now has a substantial 8′ Principal and upper work to match. We also added a new Twelfth and Seventeenth to fill out the chorus. The existing Koppel Flöte was adequate, but the 8′ Nason Gedeckt and 8′ Quintadena were too similar, so I moved the Nason Gedeckt to the Quintadena chest and added a new, larger-scaled 8′ Bourdon. The 16′ Dulzian was moved to a new unit chest, and I added a new large-scale 8′ Flûte Harmonique. The Flûte Harmonique pipes were then voiced to be commanding as a solo stop in the treble, yet work well in the ensemble.

The Swell division only needed the addition of a new 8′ Diapason of adequate scale. Every other need in that division was addressed during the tonal finishing that was done later.

The Positiv division was next on the list. It was typical of the period, yet still an effective division. I moved the 8′ Geigen from the Choir to a new unit chest above the Great in order to provide some foundation at 8′ and 4′ pitches. As a result, we also discovered that it makes an impressive 16′ Double on the Great. The existing 11⁄3′ was of flute tone, so I replaced it with pipes from the old Great IV Mixture. The remaining issues again were done during the final tonal work.

The Choir division was an interesting challenge. It was originally designed as the enclosed division to partner with the Positiv. After the 1994 revision, the Choir was left on its own. It had the 8′ Geigen, a hybrid 4′ Gemshorn/Principal, a pair of Erzählers, a large 8′ Clarinet, and a 4′ Hautbois. It was not a lot to work with.

By the time we addressed the Choir, work on the other divisions had rapidly depleted funding for the project. Fortuitously, the church had several vintage ranks in storage from a donated Kimball, and I had several nice stops remaining from various earlier projects. For example, I had a lovely 8′ Reuter Spitz Principal that we installed on the now vacant 8′ Geigen chest. The church had a wonderful 8′ open wood Kimball Claribel Flute that was installed where the 8′ Krummhorn had been. I had a new chest built to hold a pretty 4′ Möller Flute d’Amour and III–IV Mixture, and Reuter built the bottom octave for the Hautbois to make it an 8′. We also added a lovely set of Kimball 8′ strings which reside in the enclosed Bombarde division that sits atop the choir. To increase versatility, there is now a knob that allows the Choir expression to operate the Bombarde expression when the strings are used on the Choir. Tonal finishing did wonders to tie together all the disparate pipework in the Choir. The division now has purpose and adds a great deal of color to the entire ensemble.

The Bombarde division also received a vintage 4′ Harmonic Flute. It adds color to the 8′ English Horn and sneaks in as a filler with the strings.

The Pedal division had the fewest needs, though we did add a larger scale 8′ Diapason to augment the existing 8′ Principal. This gave the Pedal a better 8′ line. The remaining work was done in the tonal finishing phase.

I cannot thank JR Neutel from Reuter enough for the marvelous job he did during the tonal finishing phase. I have worked with him on many instruments in the last twenty years. He has limitless energy coupled with complete mastery of dealing with pipework that appears to be hopeless. We spent over three weeks going through every pipe in the organ. The completed organ now has the weight to carry the length of the nave, but it is still nimble enough to play the lightest literature. I would also like the thank G. Mark Caldwell, Marty Larsen, Tom Birkett, and John Riester for their assistance in making the completed instrument possible.

—Roger Banks

Oklahoma City, Oklahoma



From Reuter Organ Company

This project is unique in that it was not conceived in the typical relationship that many equate with a “main-line builder” and the “sales representative.” In this case, Roger Banks called upon us to consult with him—a partnership of equals. Together we discussed numerous ideas of how to tonally enhance the organ, culminating with all of the specific details needed to complete this tonal enhancement, including final pipe scales and wind pressures to achieve the objective. Reuter was then given the opportunity to provide the new pipes and chests that Roger needed. Reuter has been fortunate to develop similar relationships with other affiliates over the past decade.

While Roger has had a fifty-plus year relationship with Reuter, he and I began working together on numerous installations, most notably back to 2001, when he first assisted me with the voicing of our flagship instrument at Saint John’s Cathedral in Albuquerque, New Mexico. I was honored when Roger asked me to take the lead on the revoicing of the organ at First Presbyterian Church. I also thank John Edwards for his confidence and support. With an instrument of this size the undertaking was daunting. Roger’s ability to “massage” new sounds out of old pipes as well as working with new pipes is second to none. With our combined abilities and weeks of on-site voicing time, the desired results were achieved.

This “new” organ at First Presbyterian, along with two other recently completed organ renovations in Oklahoma City (Christ the King Catholic Church and Oklahoma City University), and a soon to be completed project at Westminster Presbyterian Church, are the culmination of a rewarding partnership and friendship with Roger. We applaud Roger and his successful career as one of the central state’s leading organ specialists and extend our deep appreciation for his leadership on this project. The renewed organ stands as a landmark instrument in the area!

—JR Neutel

Reuter Organ Company



From John L. Edwards

Standing for over half a century on its northwest Oklahoma City site, the fourth house of worship of First Presbyterian Church is a grand Gothic structure of Tennessee limestone. In addition to its impressive stained glass windows, the building boasts four pipe organs: chapel (1956 Austin, two manuals, fifteen ranks); Watchorn Hall (1956 M. P. Möller, two manuals, four ranks); choir room (1965 Walcker, two manuals, eleven ranks); and sanctuary (1964 M. P. Möller, four manuals, seventy-one ranks; 2016 Banks-Reuter, four manuals, nintety-one ranks). The “4X4 Organ Concert” is unique and very popular to the Oklahoma City community, four organists playing four pipe organs moving from venue to venue.

From its 1889 beginnings, the church has regarded music as a primary form of worship and, to that end, has had many well-known church musicians leading that endeavor. John S. C. Kemp served as minister of music from 1949 to 1968 with encore service from 1983 to 1986. During these periods of service, his wife, Helen developed her expansive work with children as well as her soaring soprano voice. In their honor, the church now has a free concert series named for them. John Blackwell followed the Kemps’ first term of service. Organists have included Wilma Jensen and Samuel C. Hutchison. Several others served shorter terms or as music interns for a year of their undergraduate studies. Those include Elaine Warner Chard, Louise Bass, Dorothy Kosanke-Elder, Greg Funfgeld, Eric Howe, Mark Lawlor, and Glenn A. Miller, among others.

While meeting for Sunday worship in Watchorn Hall until completion of the sanctuary in 1964, an organ committee chaired by DeWitt B. Kirk and then-organist Gale Norman Enger chose the M. P. Möller Organ Co. of Hagerstown, Maryland, to build the new instrument for the 1,400-seat sanctuary. Completed in 1964, Opus 9862 had four manuals with seventy ranks in the chancel and one “En Chamade” rank at the rear of the church. Wilma Jensen oversaw
the installation.

In 1992 a decision was made to purchase a new console and solid-state operating system, with preparations for future additions. The console plus four ranks were added in 1994. Organ committee chair, Dargan Mayberry, organist John L. Edwards, and director of music Michael W. Yeager, along with consultants John Balka, Fred Haley, Jon Olin Roberts, Frederick Swann, and Laura van der Windt worked together with the McCrary Pipe Organ Service of Oklahoma City, Oklahoma, to complete this project.

By 2014 the pneumatics to the Swell expression shades had failed. It was decided to replace them with new electric motors for the operation that also allowed for expanded opening of the louvers. This improvement then led to the discussion of revoicing existing ranks and adding ranks of pipes to better facilitate the lack of fundamental tone experienced in the nave of the church. Roger A. Banks, current curator of the instruments at First Presbyterian Church, in conjunction with JR Neutel of the Reuter Organ Company, presented a plan for rescaling certain pipes, adding new pipework, and relocating several stops to alternate divisions. Additionally, some vintage pipework was available and incorporated into the instrument, notably from organs made by W. W. Kimball, Estey, M. P. Möller, Reuter, McManis, and even a Robert Morton Clarinet. The Hooded Tuba was sent to Reuter to be revoiced for a more commanding and appropriate Tuba quality. All in all, sixteen ranks were added in 2016, and the organ became an instrument of ninety-one ranks with 5,269 pipes. I was honored to present an inaugural recital on May 1, 2016, which also marked my twenty-fifth anniversary on staff at First Presbyterian Church.

Working closely with Roger Banks has been a highlight for me and for our church. He has become family to us. His knowledge and expertise are unsurpassed! Roger and JR Neutel, president of the Reuter Pipe Organ Company, went through every single pipe of the instrument, critically listening and voicing each to give the best and necessary response to the cavernous space of the sanctuary. The finished result is a warm and rich singing sound extending into the nave, especially noticed by stronger congregational singing.

­—John L. Edwards, organist

First Presbyterian Church

Photo credit: Kathy Rangel, except where noted



GREAT (Manual II)

16′ Geigen (ext 8′, 1–12 electronic)

16′ Quintadena 73 pipes

16′ Claribel Flute (Ch)

8′ Principal 61 pipes

8′ Geigen  73 pipes

8′ Flûte Harmonique 61 pipes

8′ Bourdon 61 pipes

8′ Quintade (ext)

51⁄3′ Quint (TC, fr 22⁄3′)

4′ Octave 61 pipes

4′ Koppelflöte 61 pipes

31⁄5′ Grossterz (TC, fr 13⁄5′)

22⁄3′ Twelfth 61 pipes

2′ Fifteenth 61 pipes

2′ Flageolet 61 pipes

13⁄5′ Seventeenth 61 pipes

IV Fourniture 11⁄3′ 244 pipes

III Scharf 1′ 183 pipes

16′ Dulzian 73 pipes

8′ Bombarde (Ped)

8′ Dulzian (ext)

Tremolo

Great to Great 16

Great Unison Off

Great to Great 4

Chimes (G2 – G4, volume 0–5)

Carillon

SWELL (Manual III, expressive)

16′ Rohrbass 73 pipes

8′ Diapason 73 pipes

8′ Viola Pomposa 61 pipes

8′ Viola Céleste 61 pipes

8′ Rohrflöte (ext)

8′ Flûte Céleste II 110 pipes

4′ Octave Diapason (ext)

4′ Praestant 61 pipes

4′ Flûte Harmonique 61 pipes

22⁄3′ Nazard 61 pipes

2′ Flachflöte 61 pipes

13⁄5′ Tierce 61 pipes

IV Plein Jeu 11⁄3′ 244 pipes

III Cymbal 1′ 183 pipes

32′ Contra Fagotto (TC, fr 16′)

16′ Fagotto 73 pipes

8′ Trompette 61 pipes

8′ Fagotto Oboe (ext)

8′ Vox Humana 61 pipes

4′ Clairon 61 pipes

Tremolo

Swell to Swell 16

Swell Unison Off

Swell to Swell 4

CHOIR (Manual I, expressive)

16′ Erzähler 73 pipes

8′ Spitz Principal 61 pipes

8′ Salicional (Bomb)

8′ Voix Céleste (Bomb)

8′ Erzähler (ext)

8′ Erzähler Céleste (TC) 49 pipes

8′ Claribel Flute 85 pipes

4′ Gemshorn Principal 61 pipes

4′ Flauto d’Amore 61 pipes

2′ Claribel Fife (ext)

III–IV Mixture 2′ 190 pipes

8′ Clarinet 61 pipes

8′ Cromorne (Pos)

8′ Hautbois 61 pipes

Tremolo

Choir to Choir 16

Choir Unison Off

Choir to Choir 4

POSITIV (floating)

16′ Quintadena (Gt)

16′ Claribel Flute (Ch)

8′ Geigen (Gt)

8′ Holz Bordun 61 pipes

4′ Geigen (Gt)

4′ Rohrflöte 61 pipes

22⁄3′ Nazat 61 pipes

2′ Prinzipal 61 pipes

13⁄5′ Terz (GG) 54 pipes

11⁄3′ Quinte 61 pipes

1′ Sifflöte 61 pipes

III Zymbel 1⁄4′ 183 pipes

16′ Dulzian (Gt)

8′ Cromorne 61 pipes

4′ Rohr Schalmei 61 pipes

Tremolo

BOMBARDE (Manual IV, expressive)

8′ Salicional Céleste II 122 pipes

8′ Orchestral Flute (TC, fr 4′)

4′ Salicet Céleste II (ext)

4′ Orchestral Flute 61 pipes

4′ Claribel Flute (Ch)

IV Harmonics 13⁄5′ 244 pipes

16′ Bombarde (TC, fr 8′)

8′ Bombarde 61 pipes

8′ Clarinet (Ch)

8′ Dulzian (Gt)

8′ English Horn 61 pipes

4′ Clairon 61 pipes

Tremolo

8′ Hooded Tuba (unenclosed) 73 pipes

4′ Tuba Clarion (ext)

Bombarde to Bombarde 16

Bombarde Unison Off

Bombarde to Bombarde 4

Chimes

HÉROÏQUE (floating, en chamade)

16′ Trompette Héroïque (TC, fr 8′)

8′ Trompette Héroïque 61 pipes

4′ Trompette Héroïque (ext)

PEDAL

64′ Gravissima (Bourdon resultant)

32′ Violone (electronic)

32′ Contre Bourdon 44 pipes

16′ Principal 32 pipes

16′ Geigen (Gt)

16′ Subbass (ext)

16′ Quintadena (Gt)

16′ Rohrbass (Sw)

16′ Erzähler (Ch)

102⁄3′ Bourdon Sub Quint (ext)

8′ Diapason 32 pipes

8′ Octave 44 pipes

8′ Geigen (Gt)

8′ Flûte Harmonique (Gt)

8′ Rohr Pommer 32 pipes

8′ Quintade (Gt)

8′ Rohrflöte (Sw)

8′ Erzähler (Ch)

51⁄3′ Bourdon Quint (ext)

4′ Choralbass (ext)

4′ Geigen (Gt)

4′ Nachthorn 44 pipes

2′ Geigen (Gt)

2′ Nachthorn (ext)

III Cornet 51⁄3′ 96 pipes

IV Rauschbass 21⁄3′ 128 pipes

32′ Contre Bombarde 85 pipes

16′ Bombarde (ext)

16′ Fagotto (Sw)

16′ Dulzian (Gt)

8′ Hooded Tuba (Bomb)

8′ Bombarde (ext)

8′ Fagotto (Sw)

8′ Dulzian (Gt)

4′ Clairon (ext)

4′ Fagotto Oboe (Sw)

4′ Rohr Schalmei (Pos)

4′ Cromorne (Pos)

2′ Clairon Doublette (ext)

2′ Rohr Schalmei (Pos)

Chimes

Carillon

Pedal Unison Off

Pedal to Pedal 4

BELLS

Glockenstern = a) Handbells; b) India Bells (a, b, or a & b)

Zimbelstern = fast/slow

COUPLERS

Great to Pedal 8, 4

Swell to Pedal 8, 4

Choir to Pedal 8, 4

Bombarde to Pedal 8, 4

Positiv to Pedal 8, 4

Héroïque to Pedal (drawknob)

Pedal Continuo to Great 8

Swell to Great 16, 8, 4

Choir to Great 16, 8, 4

Bombarde to Great 16, 8, 4

Positiv to Great 16, 8, 4

Héroïque to Great (drawknob)

Swell to Choir 16, 8, 4

Bombarde to Choir 16, 8, 4

Positiv to Choir 16, 8, 4

Héroïque to Choir (drawknob)

Choir to Swell 16, 8, 4

Bombarde to Swell 16, 8, 4

Positiv to Swell 16, 8, 4

Héroïque to Swell (drawknob)

Great to Bombarde 16, 8, 4

Positiv to Bombarde 16, 8, 4

Héroïque to Bombarde (drawknob)

REVERSIBLES

Great to Pedal (thumb and toe)

Swell to Pedal (thumb and toe)

Choir to Pedal (thumb and toe)

Bombarde to Pedal (thumb)

Positiv to Pedal (toe)

Tutti (thumb and toe)

Glockenstern (toe)

Zimbelstern  (toe)

32′ Contre Bourdon (toe)

32′ Violone (toe)

32′ Contre Bombarde (toe)

COMBINATIONS (99 memory levels)

Generals: 1–10 (thumb and toe)

Generals: 11–20 (toe)

Great: 1–8 (thumb)

Swell: 1–8 (thumb)

Choir: 1–8 (thumb)

Positiv: 1–3 (thumb)

Bombarde: 1–5 (thumb)

Pedal: 1–3 (toe); 4–8 (thumb)

Combination Setter Button (thumb)

General Cancel (thumb)

ACCESSORIES

Drawknob console (movable)

Swell/Choir/Bombarde expression pedals

Crescendo pedal (four crescendo sequences)

Tutti (programmable)

All Swells to Swell

Bombarde to Choir Expression (drawknob)

Tuba Non-Coupling On/Off (drawknob)

Great/Choir Transfer

Peterson Operating System and Piston Sequencer

Next/Previous Pistons (thumb and toe)

Héroïque Power On/Off (toggle switch)

Adjustable Bench, in memory of Wanda L. Bass

4 manuals, 91 ranks

M. P. Möller Opus 9862, 1964, 4 manuals, 71 ranks; 1994, new console, 4 manuals, 75 ranks; 2016, tonal revisions/additions by Roger A. Banks and Reuter Organ Co. Tonal finishing by Roger A. Banks and JR Neutel, president, Reuter Organ Co.

Great 1,195 pipes

Swell 1,366 pipes

Choir 702 pipes

Positiv 725 pipes

Bombarde 683 pipes

Heroïque 61 pipes

Pedal 537 pipes

Total: 5,269 pipes

Church website: https://fpcokc.org.

Russell Meyer & Associates, Lawrenceville, Georgia, Opus 14

First Presbyterian Church, Clarkesville, Georgia

Historic First Presbyterian Church of Clarkesville, Georgia, was built in 1848 by Jarvis Van Buren, a first cousin of President Martin Van Buren. The first pipe organ in the building was installed in the rear gallery by the Greenwood Pipe Organ Company in 1983.

The Atlanta Pipe Organ Sales & Service Company rebuilt and enlarged the Greenwood organ to seven ranks in 1989, retaining a set of twelve old 16′ Bourdon pipes, a 4′ Principal, a tenor-C Dulciana, a set of swell shades, a set of Maas-Rowe chimes, and a rebuilt two-manual drawknob console originally made by the Skinner Organ Company in 1926 for First Methodist Church of Hendersonville, North Carolina. The 1989 organ included a new organ case, five ranks of new pipes manufactured by the Wicks Organ Company, and entirely new electro-mechanical windchests with schwimmers. The Great division consisted of two unenclosed ranks—an 8′ Principal and a 4′/2′ unit Octave—plus numerous borrowed stops from the Swell division. The Swell comprised an 85-note unit Rohr Flute, a 4′ Principal, a 37-note, tenor-C Tierce, and a pair of 49-note, tenor-C dulcianas without common bass. Because the organ had only one flute rank of 8′ pitch with a 16′ extension, the soft 16′ pedal stop (activated by means of dual valves) differed from the loud 16′ stop only in its lowest octave. The organ possessed no reed tone.

Russell Meyer & Associates were contracted to rebuild and enlarge the organ in 2020. We added six ranks of pipes from M. P. Möller Opus 9739 (1962), originally installed in Saint Mary-in-the-Highlands Episcopal Church, Cold Spring, New York. To make the Great division more independent from the Swell, we added a III–IV rank mixture with its quints derived from a 49-note 1-1⁄3′ rank and its unisons from a 49-note 1′ rank. We also added a delightful 73-note wooden Gedeckt and moved the former 49-note Dulciana Celeste from the Swell along with twelve Haskell bass pipes added from our inventory. We also included a borrowed 16′ voice in the Great that produces a balanced level of gentle 16′ manual tone not achievable by the clumsier means of a suboctave coupler.

In the Swell division we replaced the previous dulcianas with a pair of moderately scaled violes. Because the unison Viole is full-compass, we were able to employ it as a common bass for a warmly singing 8′ extension of the existing 4′ Principal, a very useful stop indeed. Perhaps most significant in terms of tonal variety was our addition of an 85-note unit 16′ Trumpet conveniently playable in every division. This Trumpet performs beautifully as both a chorus reed and a solo stop.

Improvements to the Pedal division include a 32′ resultant and a gentle 16′ stop that retains a different character and softer volume from its louder sister throughout the entire compass of the pedalboard. The provision of cantus stops also adds to the versatility of the instrument. It is quite surprising how effectively the revised Pedal division undergirds the full ensemble, yet is able to do almost anything the organist asks of it, be it a quiet bass, a sweet melody, or a bold pedal solo.

To accommodate the added ranks, we expanded the organ case in matching appearance to double its previous size. We retained the existing console shell, bench, keyboards, and pedalboard but supplied all new thumb pistons, toe studs, drawknobs, tilting tablets, and a digital console clock. We manufactured new key slips, stop jambs, coupler rail, and music rack, and provided LED console lighting. We reconfigured the winding system and built new electro-mechanical windchests for five ranks, two additional schwimmers, and a seven-bell Zimbelstern of our own design. A new Opus-Two control system provides a 250-level combination action, piston sequencer, transposer, and built-in record/playback that operates totally on internal memory. We also installed a new 64-stage electric swell motor, as well as LED work lights inside the organ case.

I acknowledge and thank my colleagues and friends who worked with me on the construction, installation, and tonal finishing of this organ: Allen Colson, Joshua Crook, Tommy McCook, Michael Proscia, Corley Easterling, Bud Taylor, and Tom Wigley. John Thomas and Stephen McCarthy assisted with the removal of the Cold Spring instrument.

We are grateful to the church Session, the congregation, and the staff for entrusting us with this project. Reverend Matthew Henderson is the pastor, Areatha Ketch is music director, and Sandra Altman is organist.

—Russell Meyer, president

Builder’s website: rmeyerpipeorgans.com

Church website: fpccga.org

GREAT (Manual I, unenclosed)

16′ Dolce Bass (ext, common bass)

8′ Open Diapason 61 pipes

8′ Gedeckt (wood) * 61 pipes

8′ Dulciana (1–12 added *) 61 pipes

4′ Octave 61 pipes

4′ Gedeckt Flute (ext 8′) * 12 pipes

2′ Super Octave  (ext 4′) 12 pipes

III–IV Mixture (1-1⁄3′, derived) * 98 pipes

8′ Trumpet (Sw)

4′ Clarion (Sw)

Chimes 21 tubes

Zimbelstern * 7 bells

Swell to Great 16

Swell to Great

Swell to Great 4

SWELL (Manual II, enclosed)

8′ Violin Diapason (ext, common bass)

8′ Rohr Bourdon 61 pipes

8′ Viole * 61 pipes

8′ Viole Celeste (TC) * 49 pipes

4′ Principal 61 pipes

4′ Rohr Flute (ext 8′) 12 pipes

2-2⁄3′ Nazard (ext 8′ Rohr Flute)

2′ Block Flute (ext 8′) 12 pipes

1-3⁄5′ Tierce (TC) 37 pipes

1-1⁄3′ Larigot (ext 8′ Rohr Flute)

16′ Double Trumpet (ext 8′) * 12 pipes

8′ Trumpet * 61 pipes

4′ Clarion (ext 8′) * 12 pipes

Tremulant

Swell to Swell 16

Swell to Swell 4

PEDAL (unenclosed)

32′ Harmonic Bass (1–12 resultant)

16′ Subbass (wood, ext Sw) 12 pipes

16′ Lieblich Gedeckt (ext Gt, soft wind)

8′ Open Diapason (1–12 fr Gt Open Diapason; 13–32 fr Gt Octave)

8′ Gedeckt Bass (Gt)

4′ Choral Bass (Gt 4′ Octave)

4′ Gedeckt Flute (Gt 8′)

16′ Double Trumpet (Sw)

8′ Trumpet (Sw)

4′ Clarion (Sw)

Great to Pedal

Swell to Pedal

Swell to Pedal 4

* added pipes

12 ranks, 756 pipes

Stephen Schnurr

Stephen Schnurr is editorial director and publisher of The Diapason, director of music for Saint Paul Catholic Church, Valparaiso, Indiana, and adjunct instructor in organ for Valparaiso University.

As one travels the John F. Kennedy Expressway on the north side of downtown Chicago, one can count the towers of five impressive church edifices that comprise the principal history of Chicago’s Polish Catholics. The heart of Chicago’s “Polonia,” the neighborhoods nearby, has been home to a large number of immigrants who came to the United States from Poland or are of Polish descent. In 1950, Chicago had the largest Polish population outside the city of Warsaw. Today, Polish is the third most frequently heard language in this city, behind English and Spanish.

This is a tale of a church founded for success with large numbers of faithful, only two generations later experiencing alarming decline. Scheduled to close, the parish managed to turn itself around and is now thriving once again, a jewel box of sacred art and architecture, a model of traditional liturgy, and a home for the performing arts, sacred and secular. While many churches have removed their organs or cannot afford to maintain them, here is a parish with no fewer than four pipe organs, all in regular use, for ritual or for concert, or both! Indeed, one could have an “organ crawl” at one address.

Saint John Cantius Catholic Church was founded in 1893 to relieve the overcrowded parish of Saint Stanislaus Kostka and other Polish parishes in this area of the city. Saint Stanislaus had become the largest parish in the world in 1892, and, thus, a division of the parish of 8,000 families had become necessary.  The mother parish was located approximately one mile away in its Patrick C. Keely-designed edifice constructed between 1877 and 1881 and housing Johnson & Son opus 553, a two-manual, thirty-three-rank organ.

The Reverend John Kasprzycki, C.R. (Congregation of the Resurrection), was appointed first pastor of Saint John Cantius, a congregation with an immediate roster of 2,000 families. In acquiring the present property on North Carpenter Street between West Fry and Chicago Avenues, some twenty residences were demolished for the new parish campus. The cornerstone of the church was laid by Archbishop Patrick A. Feehan on September 4, 1893. A crowd of an estimated 25,000 attended the event, with music provided by twenty-seven Polish singing societies. By November, the parish school was opened in the basement section of the building. The rectory, located at the corner of Carpenter and Fry, was blessed on December 20. The lower church was blessed by Feehan on Christmas Eve, and the first Mass was celebrated the following day, the traditional founding date of the parish. The upper church was completed and blessed by Archbishop Feehan on December 11, 1898. Construction cost was $130,000. The Romanesque edifice was designed by Adolphus Druiding. A German native then living in Chicago, Druiding designed Saint George and Saint Hedwig Catholic Churches in Chicago, as well. Seating 2,000 persons, Saint John Cantius Church measured 230 feet long, 107 feet wide.

Father Eugene Sedlaczek, C.R., was named second pastor of Saint John Cantius in 1899. Within two years, he oversaw the interior decoration of the church.

The Reverend Stanislaus Rogalski, C.R., was named fourth pastor in 1902. The following year, construction for the present school building commenced, completed in November. The school and the rectory were designed by Henry Schlacks of Chicago. A clock and bells were installed in the 130-foot tower and the church interior painted. Father John Kosinski, C.R., became fifth pastor in 1909. Under his leadership, magnificent stained-glass windows were installed in the church. The Reverend Stanislaus Siatka, C.R., became pastor in 1915. New concrete stairs of monumental proportions were created in front of the church, the basement was remodeled to become an auditorium, and a convent constructed. (At one point, the convent housed forty-seven School Sisters of Notre Dame.) By the parish silver jubilee on December 25, 1918, membership climbed to 23,000 persons, with 2,000 children enrolled in the school.

In the 1950s, numerous neighborhood homes were demolished to make way for what would become known as the Kennedy Expressway, a project that drastically changed the parish environs. Parish membership, which had been in decline, would drop even more drastically. The school closed in 1967. At one point, the parish itself was to be shuttered.

The decline of the parish was reversed in the late 1980s with the appointment of the Reverend C. Frank Phillips, C. R., as pastor, and the parish was soon vibrant and growing, with membership coming from great distances. The Canons Regular of Saint John Cantius, a religious community of men, was founded in the parish in 1998, and this organization now administers the parish. The church interior has been thoroughly restored and enhanced, complemented with countless religious artworks now on display throughout the entire parish campus.

The first organ of record in Saint John Cantius Church was A. B. Felgemaker & Son Opus 723, installed in the choir gallery (the upper of two balconies) in the rear of the nave in 1900.

1900 A. B. Felgemaker & Son Opus 723

GREAT (Manual I)

16′ Double Open Diapason 61 pipes (metal)

8′ Open Diapason (metal) 61 pipes

8′ Doppel Floete (wood) 61 pipes

8′ Viola da Gamba (metal) 61 pipes

8′ Dulciana (metal) 61 pipes

4′ Octave (metal) 61 pipes

4′ Flute d’Amour 61 pipes (wood & metal)

3′ Octave Quinte (metal) 61 pipes

2′ Super Octave (metal) 61 pipes

III Mixture (metal) 183 pipes

8′ Trumpet (metal) 61 pipes

SWELL (Manual II, enclosed)

16′ Bourdon 61 pipes (treble and bass, wood)

8′ Open Diapason 61 pipes (wood & metal)

8′ Stopped Diapason (wood) 61 pipes

8′ Salicional (metal) 61 pipes

8′ Aeolina (metal) 61 pipes

4′ Gemshorn (metal) 61 pipes

4′ Flute Harmonique 61 pipes (metal)

2′ Flageolet (metal) 61 pipes

III Dolce Cornet (metal) 183 pipes

8′ Oboe & Bassoon (metal) 61 pipes

PEDAL

16′ Double Open Diapason 30 pipes (wood)

16′ Bourdon (wood) 30 pipes

8′ Violoncello (metal) 30 pipes

8′ Floete (wood) 30 pipes

Couplers

Great to Pedal

Swell to Pedal

Swell to Great in Sub-Octave

Swell to Great

Swell to Great in Super Octave

Accessories

Forte Combination Great and Pedal Stops

Piano Combination Great and Pedal Stops

Forte Combination Swell and Pedal Stops

Piano Combination Swell and Pedal Stops

Tremolo

Great to Pedal Reversible

Balanced Swell Pedal

Balanced Crescendo Pedal

Bellows Signal

Wind Indicator

The January 1, 1919, issue of The Diapason noted that a W. W. Kimball Company organ was dedicated at Saint John Cantius in December of 1918. Further information on this instrument has not come to light, and it may not have been installed in the church. It is possible that it was placed in the lower church-auditorium or elsewhere.

In 1922, Geo. Kilgen & Son of Saint Louis, Missouri, installed a new three-manual organ in the upper balcony of the church, Opus 3118. In 1927, the builder added an Echo division, placed behind the main altar, as their Opus 3932.

1922/1927 Geo. Kilgen & Son Opus 3118/3932

GREAT (Manual II, enclosed?)

8′ First Open Diapason

8′ Second Open Diapason

8′ Gross Flute

8′ Doppel Flute

8′ Gamba

4′ Octave

4′ Harmonic Flute

2′ Octave

8′ Tuba

Great to Great 16

Great Unison Off

Great to Great 4

Swell to Great 16

Swell to Great 8

Swell to Great 4

Choir to Great 16

Choir to Great 8

Choir to Great 4

Echo to Great 8

SWELL (Manual III, enclosed)

16′ Lieblich Gedeckt

8′ Open Diapason

8′ Stopped Flute (ext 16′ Lieb Ged)

8′ Salicional

8′ Voix Celeste

8′ Muted Viole

4′ Violina

4′ Flute

16′ Fagotto

8′ Cornopean

8′ Fagotto (ext 16′ Fagotto)

8′ Vox Humana

Tremolo

Swell to Swell 16

Swell Unison Off

Swell to Swell 4

Echo to Swell 8

CHOIR (Manual I, enclosed)

16′ Quintadena

8′ Violin Diapason

8′ Melodia

8′ Quintadena (ext 16′ Quintadena)

8′ Dulciana

4′ Flute d’Amore

2′ Piccolo

8′ Clarinet

Tremolo

Choir to Choir 16

Choir Unison Off

Choir to Choir 4

Swell to Choir 16

Swell to Choir 8

Swell to Choir 4

Echo to Choir 8

ECHO (Manual IV, enclosed)

16′ Bourdon

8′ Open Diapason

8′ Bourdon (ext 16′ Bourdon)

8′ String

8′ Celeste (TC)

4′ Flute

2′ Zart Flute (ext 4′ Flute)

8′ Vox Humana

Tremolo

Chimes

PEDAL

32′ Resultant

16′ Open Diapason (wood)

16′ Open Diapason (metal)

16′ Bourdon

16′ Lieblich Gedeckt (Sw 16′ Lieb Ged)

8′ Gamba (Gt 8′ Gamba)

8′ Bass Flute (ext 16′ Bourdon)

8′ Dolce Flute (Sw 16′ Lieb Ged)

16′ Trombone

16′ Fagotto (Sw 16′ Fagotto)

8′ Fagotto (Sw 16′ Fagotto)

Great to Pedal 8

Great to Pedal 4

Swell to Pedal 8

Swell to Pedal 4

Choir to Pedal 8

Choir to Pedal 4

Echo to Pedal 8

By the early 1990s, a one-manual, mechanical-action organ was relocated to the left balcony of the nave. The builder of this instrument was never ascertained, though interior evidence leads one to believe it was likely built around 1881 and perhaps in the New York City area. The organ has since been removed from the church and is now in storage at the retreat facility of the Canons Regular of Saint John Cantius in Lawton, Michigan. It has a 55-note compass (C–G, no high F#) and a Pedal compass of 27 notes (C–D).

MANUAL

8′ Principal

8′ Gamba

8′ Melodia

4′ Flute

2′ Open

PEDAL

16′ Subbass

Manual to Pedal Coupler

About 1996, the Kilgen organ in the rear gallery of the nave was rebuilt by Daniel Bogue and Associates of Downers Grove, Illinois, which closed in 1989. Some pipework was incorporated from an organ formerly in Alvernia High School of Chicago. This organ was removed in late 2011.

1996 Daniel Bogue and Associates organ

GREAT (Manual II, enclosed with Choir, south side)

8′ Principal

8′ Flute (stopped)

4′ Octave (5 basses in façade)

4′ Flute (harmonic from middle C)

2′ Principal (ext 4′ Octave)

IV Fourniture (1′)

8′ Trompette (harmonic from B3)

4′ Clarion (ext 8′ Trompette)

2 blank tabs

Great to Great 16

Great Unison Off

Great to Great 4

Swell to Great 16

Swell to Great 8

Swell to Great 4

Choir to Great 16

Choir to Great 8

Choir to Great 4

Echo to Great 8

SWELL (Manual III, enclosed, north side)

16′ Bourdon (wood)

8′ Principal

8′ Bourdon (ext 16′ Bourdon)

8′ Gamba

8′ Gamba Celeste (TC)

4′ Principal (ext 8′ Principal)

4′ Flute (open wood, harmonic from middle C)

2-2⁄3′ Nazard

2′ Principal

1-3⁄5′ Tierce

IV Plein Jeu

16′ Fagotto (1–12 half-length)

8′ Trumpet

8′ Fagotto (ext 16′ Fagotto)

4′ Clarion (ext 8′ Trumpet)

Tremolo

Swell to Swell 16

Swell Unison Off

Swell to Swell 4

Echo to Swell 8

CHOIR (Manual I, enclosed with Great, south side)

16′ Gemshorn (12 Quintaton basses)

8′ Violin Diapason

8′ Hohl Flute (wood, 12 stopped basses, remainder open)

8′ Gemshorn (ext 16′ Gemshorn)

8′ Gemshorn Celeste (TC)

4′ Principal (ext 8′ Violin Diapason)

4′ Gedeckt (wood)

2′ Flute (harmonic from tenor C)

1-1⁄3′ Larigot (ext 4′ Gedeckt)

III Cymbel

8′ Cromorne

Tremolo

1 blank tab

Choir to Choir 16

Choir Unison Off

Choir to Choir 4

Swell to Choir 16

Swell to Choir 8

Swell to Choir 4

Echo to Choir 8

ECHO (Enclosed, floating)

8′ Bourdon

8′ String

8′ Celeste (TC)

4′ Flute (ext 8′ Bourdon)

2′ Flute (ext 8′ Bourdon)

8′ Vox Humana

1 blank tablet

Tremolo

Chimes

PEDAL

32′ Resultant (fr 16′ Bourdon)

16′ Double Open Diapason (wood, north side)

16′ Contra Bass (E1–E4 in façade, south side)

16′ Bourdon (north side)

16′ Lieblich Gedeckt (Sw 16′ Bourdon)

8′ Octave (ext 16′ Contra Bass)

8′ Bass Flute (ext 16′ Bourdon)

8′ Gedeckt (Sw 16′ Bourdon)

4′ Choral Bass (ext 16′ Contra Bass)

4′ Flute (Sw 16′ Bourdon)

2′ Octavin (ext 16′ Contra Bass)

16′ Contra Trumpet (ext Great 8′ Trompette, full-length)

16′ Contra Fagotto (Sw 16′ Fagotto)

8′ Trumpet (Gt 8′ Trompette)

4′ Clarion (Gt 8′ Trompette)

Great to Pedal 8

Swell to Pedal 8

Choir to Pedal 8

Echo to Pedal 8

ECHO PEDAL (enclosed with Echo)

16′ Bourdon (ext Echo 8′ Bourdon)

8′ Bourdon (fr Echo 8′ Bourdon)

Accessories

10 General Pistons (thumb)

6 Great Pistons and Cancel (thumb)

6 Swell Pistons and Cancel (thumb)

6 Choir Pistons and Cancel (thumb)

6 Echo Pistons and Cancel (thumb)

6 Pedal Pistons and Cancel (thumb)

General Cancel (thumb)

Great to Pedal reversible (thumb and toe)

Swell to Pedal reversible (thumb and toe)

Choir to Pedal reversible (thumb and toe)

Balanced Swell expression shoe

Balanced Great/Choir expression shoe

Balanced Crescendo shoe (with indicator light)

Combination Lock (key)

Sforzando Reversible (thumb and toe, with indicator light)

Wind Indicator

In 2005, Saint John Cantius Church commissioned one of the last organs built by Oberlinger Orgelbau of Windesheim, Germany. The one-manual, mechanical-action instrument resides on the main floor of the nave. Manual compass is 51 notes (C–D). A lever transposes the organ one half-step down (A=415 Hz). The instrument was blessed on May 14, 2005, by the Most Reverend Basil Meeking, Bishop Emeritus of Christchurch, New Zealand.

2005 Oberlinger organ

MANUAL

8′ Traversflöte (tenor B, wood)

8′ Copula (stopped wood)

4′ Gedackt (30 basses stopped wood, remainder open metal)

2′ Principalflöte (18 capped metal basses, remainder open metal)

1-1⁄3′ Quinte (24 capped metal basses, remainder open metal)

1–2f Cymbel (1⁄2′)

Accessory

H–C (transposer)

In August 2008, a two-manual, mechanical-action organ built in 1991 by Alfred Wild of Gottenhouse, France, was installed in the sanctuary of the church. It was on loan to the parish by a nearby resident who was a friend of Father Phillips. The stopknobs are unlabeled. Temperament is Kirnberger. Manual compass is 56 notes (C–G). In October 2015, the organ was moved to the lower balcony at the rear of the church, so that it could be used with the choir or instrumentalists when a small organ is desirable. In 2017 the instrument was returned to its owner.

1991 Alfred Wild organ

MANUAL I

8′ Gedackt (wood)

4′ Chimney Flute

2′ Principal

MANUAL II

8′ Gedackt (fr Manual I 8′ Gedackt)

8′ Regal

Couplers

Manual I to Pedal

Manual II to Pedal

Manual II to Manual I

The lower balcony at the rear of the nave housed an organ installed in January 2007. The instrument was built by Allyn Hoverland for his residence and sold to the church in December 2006. Wind pressure is 21⁄2 inches. The console is recycled from an M. P. Möller organ. The organ was blessed by Auxiliary Bishop Thomas J. Paprocki on Sunday, February 11, 2007. When the upper gallery organ was removed in preparation for the restored Casavant organ described below, this instrument was the primary organ in the church for several years. This instrument was sold to Saint Mary Catholic Church, Iron Mountain, Michigan, and moved there in late 2014 by
J. L. Weiler, Inc., of Chicago.

Specification of the Allyn Hoverland organ

MANUAL I

8′ Principal (B)

8′ Stopped Flute (A, 1–49; E, 50–61)

8′ Chimney Flute (A, 1–12; C, 13–61)

4′ Principal (B)

4′ Block Flute (A, 1–12; E, 13–61)

2-2⁄3′ Quinte (D)

2′ Block Flute (E)

III Mixture (D, F)

II Mixture (F)

MANUAL II

8′ Block Flute (A, 1–24; E, 25–61)

8′ Chimney Flute (A, 1–12; C, 13–61)

4′ Chimney Flute (C)

2′ Principal (B, 1–49; E, 50–61)

1-1⁄3′ Quinte (D)

PEDAL

16′ Bourdon (A, 1–24; C, 25–32)

10-2⁄3′ Quint Flute (A, 1–17; C, 18–32)

8′ Principal (B)

8′ Chimney Flute (A, 1–12; C, 13–32)

5-1⁄3′ Quinte (A, 1–5; C, 6–12; D, 13–32)

4′ Principal (B)

4′ Chimney Flute (C)

2-2⁄3′ Quinte (D)

2′ Block Flute (E)

Mixture III [sic] (F)

Accessories

10 General pistons (1–10, thumb; 1–5, toe)

5 Manual I pistons (thumb and toe)

5 Manual II pistons (thumb)

General Cancel (thumb)

Analysis

A=16′ Bourdon, c. 1890, builder unknown, 61 pipes

B=8′ Principal, 12 basses c. 1980 M. P. Möller, remainder 1978 Casavant, 73 pipes

C=4′ Chimney Flute, c. 1870, builder unknown, 61 pipes

D=2-2⁄3′ Quinte, builder unknown, 61 pipes

E=2′ Block Flute, 1978 Casavant, 61 pipes

F=II Mixture (1′), 1978 Casavant, 122 pipes

The lower auditorium of the church building houses a 1927 Wurlitzer organ that was installed by Century Pipe Organs of Minneapolis, Minnesota. The Wurlitzer was built for the Terrace Theatre of New York City and, in 1935, moved by the builder to the studios of radio station WOR of the Mutual Broadcasting System in New York City. At Saint John Cantius, the two-manual, seven-rank, electro-pneumatic-action organ (Style “E”) was placed in a special chamber built on the stage of the auditorium. Manual compass is 61 notes (C–C); Pedal compass (concave, radiating pedalboard) is 32 notes (C–G). The project was completed in 2013.

The console has stop-tongue control, with the following colors: reeds in red; strings in mottled yellow; flues in white; couplers in black. Originally, the Tibia, Vox Humana, and Trumpet ranks were in a separate expression box, though the entire organ is now in one enclosure. There are today still two expression shoes.

In 2015, J. L. Weiler, Inc., of Chicago carried out work on the console, improving its overall appearance, fine-tuning the key regulation and response, revising atypical nomenclature as it applies to console controls, and tidying the wiring in the console. The existing solid-state control system was upgraded to its latest version.

1927 Wurlitzer Opus 1818

Analysis

8′ Tibia Clausa 85 pipes

16′ Bourdon/Concert Flute 97 pipes

16′ Diaphone/Diaphonic Diapason 85 pipes

8′ Trumpet 61 pipes

8′ Violin 73 pipes

8′ Violin Celeste 73 pipes

8′ Vox Humana 61 pipes

ACCOMPANIMENT (Manual I)

8′ Trumpet

8′ Diaphonic Diapason

8′ Tibia Clausa

8′ Violin (Violin and Celeste)

8′ Concert Flute

8′ Vox Humana

4′ Octave

4′ Piccolo (Tibia Clausa)

4′ Viol (Violin and Celeste)

4′ Flute

4′ Vox Humana

2-2⁄3′ Twelfth (Bourdon)

2′ Piccolo (Bourdon)

Accompaniment Octave

Chrysoglott (G1–G5)

Snare Drum (reiterates)

Tambourine (reiterates)

Castanets (reiterates)

Chinese Block

Tom Tom

Jazz Cymbal

Triangle

Sleigh Bells

Accompaniment Second Touch

8′ Trumpet

8′ Open Diapason

8′ Tibia Clausa

4′ Piccolo (Tibia)

Chrysoglott

Glockenspiel

Cathedral Chimes

Accomp Traps

SOLO (Manual II)

16′ Trumpet (TC)

16′ Diaphone

16′ Tibia Clausa (TC)

16′ Violone (TC, two ranks)

16′ Bourdon

16′ Vox Humana (TC)

8′ Trumpet

8′ Diaphonic Diapason

8′ Tibia Clausa

8′ Violin (Violin and Celeste)

8′ Concert Flute

8′ Vox Humana

5-1⁄3′ Fifth (Tibia Clausa)

4′ Octave

4′ Piccolo (Tibia Clausa)

4′ Viol (Violin and Celeste)

4′ Flute

2-2⁄3′ Twelfth (Tibia Clausa)

2′ Piccolo (Tibia Clausa)

2′ Fifteenth (Violin)

2′ Piccolo (Bourdon)

1-3⁄5′ Tierce (Tibia Clausa)

1′ Fife (Bourdon)

Solo Sub Octave

Solo Octave

Xylophone (C2–C5)

Glockenspiel (G2–C5)

Chrysoglott (G1–G5)

Sleigh Bells (C2–C4, tuned, reiterates)

Chimes (G2–C4) 18 tubes

PEDAL

16′ Diaphone

16′ Bourdon

8′ Trumpet

8′ Diaphonic Diapason

8′ Tibia Clausa

8′ Cello

8′ Flute

Accomp to Pedal

Bass Drum

Kettle Drum (reiterates)

Tap Cymbal

Crash Cymbal

Tremulants

Tibia Clausa Trem

Solo Tremulant

Main Tremulant

Vox Humana Trem

Accessories

5 Accompaniment pistons (thumb), usable as divisionals or generals

5 Solo pistons (thumb), usable as divisionals or generals

Celestes Off

Accomp Perc/Pedal

Bell (right Accompaniment keycheeck)

Balanced Main expression shoe

Balanced Solo expression shoe

Balanced Crescendo shoe

Range

Set

Unlabeled toe studs for effects: Bird, Auto Horn, Train Whistle, Horses Hooves, Fire Gong

The former convent, now known as the Canonry, has a chapel named for Saint Joseph housing a two-manual, three-rank, electro-pneumatic-action Casavant organ, built for the chapel of the Servantes de Jesus Marie, Rimouski, Québec, Canada. This instrument was installed at Saint John Cantius in Autumn 2010 by Jeff Weiler and Associates of Chicago. The console of the organ is located in a balcony, while the pipework is in a free-standing case on the floor. Manual compass is 61 notes (C–C); Pedal compass (concave, radiating pedalboard) is 32 notes (C–G). The entire organ is enclosed.

1957 Casavant Opus 2403

GRAND ORGUE (Manual I)

16′ Bourdon 85 pipes

8′ Principal (TC, 12 basses 61 pipes from 8′ Flute at 8′ and 4′ pitches)

8′ Bourdon (ext 16′ Bourdon)

8′ Dulciane (TC, 12 basses 73 pipes from 8′ Flute)

4′ Violina (ext 8′ Principal)

4′ Dulcet (ext 8′ Dulciane)

4′ Flute d’Amour (ext 16′ Bourdon)

2-2⁄3′ Nazard (ext 8′ Dulciane)

2′ Doublette (ext 8′ Dulciane)

Recit au Grand Orgue

RECIT (Manual II)

8′ Principal (G.O. 8′ Principal)

8′ Bourdon (G.O. 16′ Bourdon)

8′ Quintaton (synthetic, Flute at 8′, Dulciane at 2-2⁄3′)

8′ Dulciane (G.O. 8′ Dulciane)

4′ Violina (G.O. 8′ Principal)

4′ Flute (G.O. 16′ Bourdon)

4′ Dulcet (G.O. 8′ Dulciane)

8′ Hautbois (synthetic, Principal at 8′, Flute at 2-2⁄3′, 12 basses from Flute at 8′ and 4′)

Tremolo

PEDALE

16′ Bourdon (G.O. 16′ Bourdon)

8′ Bourdon (G.O. 16′ Bourdon)

4′ Principal (G.O. 8′ Principal)

4′ Flute (G.O. 16′ Bourdon)

4′ Dulcet (G.O. 8′ Dulciane)

Gr. Orgue a la Pedale

Recit a la Pedale

Accessories

3 Grand Orgue and Pedale pistons (thumb)

3 Recit pistons (thumb)

Balanced expression shoe

Balanced Crescendo shoe (with rotating indicator dial)

On Sunday, October 20, 2013, a historic pipe organ that has been part of Chicago’s history for more than three-quarters of a century was dedicated in its new home, Saint John Cantius Church. The afternoon and evening activities commenced with a blessing of the organ by His Eminence, the late Francis Cardinal George, OMI, Archbishop of Chicago, followed by a Pontifical Latin High Mass, celebrated by the Most Reverend Joseph N. Perry, Auxiliary Bishop of Chicago. Choral and organ works by Louis Vierne, Healey Willan, Charles-Marie Widor, and Marcel Dupré filled the nave with sound. An over-capacity crowd filled the church, including its side balconies, with additional faithful standing in the aisles. Following a dinner catered in the church’s lower level, the evening was capped with a dedicatory recital.

The event was the conclusion of a three-year restoration and relocation project for Casavant Frères opus 1130, built for Saint James Methodist Episcopal Church of the Kenwood neighborhood on the South Side of Chicago. Saint James, founded in 1896, was once attended by several of Chicago’s great commerce giants, including the Swift and Harris families of meatpacking and banking fame. In 1915, Gustavus F. Swift donated a four-manual Casavant organ built in the company’s South Haven, Michigan, plant. The Victorian Gothic church and its organ burned in 1924. The congregation commissioned Chicago’s Tallmadge & Watson to design an expansive new building, again in the Gothic style, completed in 1926. For this edifice, Tina Mae Haines, arguably Chicago’s finest female organist, lobbied the church’s leaders for a new, four-manual Casavant organ, despite pressure to purchase a Skinner organ, like many other wealthy churches. Miss Haines won her argument, and Opus 1130 was built to her specification, the funds again donated by the Swift family, $28,890. (M. P. Möller installed its Opus 4605, a two-manual, ten-rank organ costing $5,100 in the chapel.) The Casavant would be one of the South Side’s finest church and concert organs. Marcel Dupré gave a memorable program at Saint James in 1937 to a capacity crowd.

Sadly, Saint James United Methodist Church closed Sunday, December 26, 2010. The author was honored to be the last person to play the Casavant organ publicly in its original home, for an impromptu hymn festival at the conclusion of the church’s final service. Andrew Szymanski, a friend who had informed me of the church’s impending closure, joined church members as we all sang, concluding with “Abide with Me” and George Frederick Handel’s “Hallelujah Chorus.” It was the first time the organ had been used in many years. Several congregants present at Saint James’s closing were present for the rededication of their organ at Saint John Cantius.

That fateful phone call from my friend informing me the church was closing made the relocation of the organ possible. If not for that, the church would have silently ended its existence; instead, I was able to make phone calls that made the connections happen for the organ to be removed.

Then followed a restoration project for Opus 1130, carried out by J. L. Weiler, Inc., of Chicago, and the organ’s builder, Casavant, in Saint-Hyacinthe, Québec, Canada. The console of the organ is located in the lower west balcony, while the remainder of the main organ is in the upper west balcony with the Echo division in the north balcony (in a transept). Nearly ninety years after its initial installation, the organ began a new era of promise. It is fondly known as “Tina Mae.”

1926 Casavant FrПres, Limitée, Opus 1130

GREAT (Manual II, 4-inch wind pressure)

16′ Double Open (metal) 73 pipes

8′ I Open Diapason (metal) 73 pipes

8′ II Open Diapason (metal) 73 pipes

8′ Doppelflöte 73 pipes (wood and metal)

8′ Gemshorn (metal) 73 pipes

4′ Octave (metal) 73 pipes

4′ Harmonic Flute (metal) 73 pipes

Mixture IV (metal) 244 pipes

8′ Trumpet (metal) 73 pipes

Chimes (from Echo)

SWELL (Manual III, enclosed, 41Џ2-inch and 7-inch wind
pressures)

16′ Bourdon (wood) 73 pipes

8′ Open Diapason (metal)* 73 pipes

8′ Violin Diapason (metal) 73 pipes

8′ Stopped Diapason 73 pipes (wood and metal)

8′ Salicional (metal) 73 pipes

8′ Viola di Gamba (metal) 73 pipes

8′ Aeoline (metal) 73 pipes

8′ II Voix Celeste (metal) 134 pipes

4′ Violina (metal) 73 pipes

4′ Flauto Trav. 73 pipes (wood and metal)*

2′ Piccolo (metal) 61 pipes

Dolce Cornet III (metal) 183 pipes

16′ Double Trumpet (metal)* 73 pipes

8′ Cornopean (metal)* 73 pipes

8′ Oboe (metal) 73 pipes

8′ Vox Humana (metal) 73 pipes

4′ Clarion (metal)* 73 pipes

Tremulant

Chimes (from Echo)

* 7-inch wind pressure

CHOIR (Manual I, enclosed, 6-inch wind pressure)

16′ Gamba (metal) 73 pipes

8′ Open Diapason (metal) 73 pipes

8′ Concert Flute 73 pipes (wood and metal)

8′ Dulciana (metal) 73 pipes

8′ Unda Maris (metal) 73 pipes

4′ Flute d’Amour 73 pipes (wood and metal)

2-2⁄3′ Nazard (metal) 73 pipes

2′ Flageolet (metal) 61 pipes

8′ Clarinet (metal) 73 pipes

8′ Cor Anglais (metal) 73 pipes

Tremulant

Celesta 61 bars

Celesta Sub (from Celesta)

SOLO (Manual IV, enclosed, 12-inch wind pressure)

8′ Stentorphone (metal) 73 pipes

8′ Gross Flute 73 pipes (wood and metal)

8′ Viole d’Orchestre (metal) 73 pipes

8′ Viole Celeste (metal) 73 pipes

8′ Tuba (metal) 73 pipes

Tremulant

ECHO (Floating, enclosed, 3-1/2-inch wind pressure)

8′ Echo Diapason (metal) 73 pipes

8′ Cor de Nuit 73 pipes (wood and metal)

4′ Fern Flöte (metal) 73 pipes

8′ Musette (metal) 73 pipes

Tremulant

Chimes (from tenor G) 25 tubes

PEDAL

32′ Double Open 12 pipes (resultant, 16′ Open Diapason, with independent quints)

16′ Open Diapason (wood) 44 pipes

16′ Bourdon (wood) 44 pipes

16′ Contra Gamba (Ch 16′ Con Gamba)

16′ Lieblich Gedeckt (Sw 16′ Bourdon)

8′ Flute (ext 16′ Open Diapason)

8′ Stopped Flute (ext 16′ Bourdon)

8′ Cello (metal) 32 pipes

16′ Trombone (metal) 32 pipes

Chimes (from Echo)

Couplers

Great to Pedal 8

Swell to Pedal 8

Swell to Pedal 4

Choir to Pedal 8

Solo to Pedal 8

Solo to Pedal 4

Echo to Pedal 8

Great to Great 4

Swell to Great 16

Swell to Great 8

Swell to Great 4

Choir to Great 16

Choir to Great 8

Choir to Great 4

Solo to Great 16

Solo to Great 8

Solo to Great 4

Echo to Great 16

Echo to Great 8

Echo to Great 4

Echo On/Great Off

Choir to Choir 16

Choir to Choir 4

Swell to Choir 16

Swell to Choir 8

Swell to Choir 4

Solo to Choir 16

Solo to Choir 8

Solo to Choir 4

Swell to Swell 16

Swell to Swell 4

Solo to Swell 8

Solo to Solo 16

Solo to Solo 4

Great to Solo 8

Swell to Solo 8

Echo to Solo 16

Echo to Solo 8

Echo to Solo 4

Echo On/Solo Off

All Swells to Swell Pedal

Accessories

10 General pistons (thumb and toe, originally 5, toe)

5 Great pistons (thumb)

7 Swell pistons (thumb)

5 Choir pistons (thumb)

3 Solo pistons (thumb)

3 Echo pistons (thumb)

5 Pedal pistons (thumb)

Sequencer Up (4 thumb, 1 toe)/Down (1 thumb)

300 memory levels

Memory + Up/ - Down (thumb, under Manual IV)

Great to Pedal reversible (thumb and toe)

Swell to Pedal reversible (toe)

Choir to Pedal reversible (thumb)

Solo to Pedal reversible (thumb)

Echo to Pedal reversible (thumb)

Swell to Great reversible (thumb)

Choir to Great reversible (thumb)

Solo to Great reversible (thumb)

Swell to Choir reversible (thumb)

Manual 16′ On/Off (thumb, with indicator)

Manual 2′ On/Off (thumb, with indicator)

General Cancellor (thumb)

Combination Adjustor (thumb)

Balanced Swell Expression Shoe

Balanced Choir Expression Shoe

Balanced Solo and Echo Expression Shoe

Balanced Crescendo Shoe (with indicator dial)

Full Organ Reversible (toe, with indicator)

Generator Indicator

Wind Indicator

The Casavant organ can be heard on a compact disc recorded by Andrew Schaeffer, St. John Cantius Presents The Nutcracker, available from Amazon and other resources. The disc includes movements from Tchaikovsky’s The Nutcracker Suite, along with selections of music appropriate for Christmas. Also available is St. John Cantius Presents Jonathan Rudy: Epic Music for Organ, similarly available from Amazon and other resources.

This year, a 32′ Contra Trombone extension of twelve full-length pipes will be added to the Pedal 16′ Trombone. A 16′ Bourdon of thirty-two pipes will be added to the Echo division to function as a pedal stop. The Bourdon pipes come from the Casavant organ that was built for Saint Paul of the Cross Catholic Church in Park Ridge, Illinois. Casavant will build the new components, and J. L. Weiler, Inc., will install everything onsite. Work is expected to be completed by August.

§

Saint John Cantius Catholic Church is once again the spiritual home to many Catholic families, most of whom drive a considerable distance on the same expressway that enticed so many parishioners to leave the parish a generation ago. The regenerated parish’s investment in music is exemplary, with multiple choirs presenting an auspicious schedule of selections. A full calendar of concert performances provides quality music to the community. Concert and theater organ programs are frequently presented. With over a century of record, the parish is poised for many more years serving the spiritual and cultural needs of the Chicago metropolitan community.

Sources

Koenig, Rev. Msgr. Harry C., STD, ed. A History of the Parishes of the Archdiocese of Chicago, Chicago, Illinois, Archdiocese of Chicago, 1980, volume 1, pp. 487–491.

Lindberg, William Edward. The Pipe Organs of A. B. Felgemaker, Late Nineteenth Century American Organ Builder, dissertation, University of Pittsburgh, Pittsburgh, Pennsylvania, 1976, p. 262.

McNamara, Denis R. Heavenly City: The Architectural Tradition of Catholic Chicago, Chicago, Illinois, Liturgical Training Publications, 2005, pp. 50–52.

Saint John Cantius: 1893–1993, Chicago, Illinois, Saint John Cantius Catholic Church, 1993.

Schnurr, Stephen J., and Dennis E. Northway. Pipe Organs of Chicago, Oak Park, Illinois, Chauncey Park Press, 2005, volume 1, pp. 116–118.

For further information: cantius.org/sacredmusic
